General data

  • Manufacturer: Nordex (Allemagne)
  • Model: N131/3600
  • Product page
  • Rated power: 3,600 kW
  • Rotor diameter: 131 m
  • Available model
  • Wind class: IEC IIs (DIBt S)
  • Offshore model: no
  • Swept area: 13,479 m²
  • Specific area: 3.75 m²/kW
  • Number of blades: 3
  • Power control: Pitch

Rotor

  • Minimum rotor speed: 7,5 rd/min
  • Maximum rotor speed: 13,6 rd/min
  • Cut-in wind speed: 3 m/s
  • Rated wind speed: 12 m/s
  • Cut-off wind speed: 25 m/s

Gear box

  • Gear box: yes
  • Stages: 3

Generator

  • Type: ASYNC DF
  • Voltage: 660 V

Tower

  • Minimum hub height: 84 m
  • Maximum hub height: 134 m

N131/3600 - Nordex - 3600 kW
Sylvain Fily - Alpha Wind

Power curve




Wind farms in the database


Full list (43 wind farms)
