Online access > Manufacturers and turbines > Enercon > E53/800

Sign up    Log in    Search

Manufacturers file (227 manufacturers)
Turbines file (2,027 turbines)
Power curves file (890 curves)

General data

  • Manufacturer: Enercon (Allemagne)
  • Model: E53/800
  • Rated power: 800 kW
  • Rotor diameter: 52.9 m
  • No more available
  • Wind class: IEC S (WZ II exp)
  • Offshore model: no
  • Swept area: 2,198 m²
  • Specific area: 2.75 m²/kW
  • Number of blades: 3
  • Power control: Pitch
  • Commissioning: 2006

Rotor

  • Minimum rotor speed: 11 rd/min
  • Maximum rotor speed: 29,5 rd/min
  • Cut-in wind speed: 2 m/s
  • Rated wind speed: 13 m/s
  • Cut-off wind speed: 25 m/s
  • Manufacturer: Enercon

Gear box

  • Gear box: no
  • Stages: -
  • Gear ratio: -
  • Manufacturer: -

Generator

  • Type: SYNC Wounded
  • Number: 1
  • Maximum speed: 28,3 rounds/minute
  • Voltage: 400 - 690 V
  • Manufacturer: Enercon

Tower

  • Minimum hub height: 60 m
  • Maximum hub height: 75 m
  • Manufacturer: SAM

E53/800 - Enercon - 800 kW

Power curve



(Air density: 1,225 kg/m3)


Wind farms in the database


Full list (376 wind farms)



Pictures

Turbine 7171
Author: François Bonnenfant - License: All right reserved
Picture reference: 7171 - Date: 2008
Turbine 7172
Author: François Bonnenfant - License: All right reserved
Picture reference: 7172 - Date: 2008
Turbine 9350
License: All right reserved
Picture reference: 9350 - Date: 2010
Turbine 9351
License: All right reserved
Picture reference: 9351 - Date: 2010
Turbine 9352
License: All right reserved
Picture reference: 9352 - Date: 2010
Turbine 9353
License: All right reserved
Picture reference: 9353 - Date: 2010
Turbine 9354
License: All right reserved
Picture reference: 9354 - Date: 2010
Turbine 9355
License: All right reserved
Picture reference: 9355 - Date: 2010
Turbine 9356
License: All right reserved
Picture reference: 9356 - Date: 2010
Turbine 9357
License: All right reserved
Picture reference: 9357 - Date: 2010
Turbine 9358
License: All right reserved
Picture reference: 9358 - Date: 2010
Turbine 9359
License: All right reserved
Picture reference: 9359 - Date: 2010
Turbine 9360
License: All right reserved
Picture reference: 9360 - Date: 2010
Turbine 9361
License: All right reserved
Picture reference: 9361 - Date: 2010
Turbine 9362
License: All right reserved
Picture reference: 9362 - Date: 2010
Turbine 9363
License: All right reserved
Picture reference: 9363 - Date: 2010
Turbine 9364
License: All right reserved
Picture reference: 9364 - Date: 2010
Turbine 9365
License: All right reserved
Picture reference: 9365 - Date: 2010
Turbine 9366
License: All right reserved
Picture reference: 9366 - Date: 2010
Turbine 9367
License: All right reserved
Picture reference: 9367 - Date: 2010
Turbine 9368
License: All right reserved
Picture reference: 9368 - Date: 2010
Turbine 9369
License: All right reserved
Picture reference: 9369 - Date: 2010
Turbine 9370
License: All right reserved
Picture reference: 9370 - Date: 2010
Turbine 9371
License: All right reserved
Picture reference: 9371 - Date: 2010
Turbine 9372
License: All right reserved
Picture reference: 9372 - Date: 2010
Turbine 9373
License: All right reserved
Picture reference: 9373 - Date: 2010
Turbine 13074
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13074 - Date: 2017
Turbine 13075
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13075 - Date: 2017
Turbine 13076
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13076 - Date: 2017
Turbine 13077
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13077 - Date: 2017
Turbine 13078
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13078 - Date: 2017
Turbine 13079
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13079 - Date: 2017
Turbine 13080
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13080 - Date: 2017
Turbine 13081
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13081 - Date: 2017
Turbine 13082
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13082 - Date: 2017
Turbine 13083
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13083 - Date: 2017
Turbine 13084
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13084 - Date: 2017
Turbine 13085
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13085 - Date: 2017
Turbine 13086
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13086 - Date: 2017
Turbine 13087
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13087 - Date: 2017
Turbine 13660
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13660 - Date: 2019
Turbine 13661
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13661 - Date: 2019
Turbine 13662
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13662 - Date: 2019
Turbine 13663
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13663 - Date: 2019
Turbine 13664
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13664 - Date: 2019
Turbine 13665
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13665 - Date: 2019
Turbine 13666
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13666 - Date: 2019
Turbine 13667
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13667 - Date: 2019
Turbine 13748
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13748 - Date: 2019
Turbine 13749
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13749 - Date: 2019
Turbine 13750
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13750 - Date: 2019
Turbine 13751
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13751 - Date: 2019
Turbine 13752
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13752 - Date: 2019
Turbine 13753
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13753 - Date: 2019
Turbine 13754
Author: Laurent Jobart - Source: Alpha Wind - License: All right reserved
Picture reference: 13754 - Date: 2019
Turbine 16035
Author: Gabriel Govaert - License: All right reserved
Picture reference: 16035 - Date: 2023
Turbine 16036
Author: Gabriel Govaert - License: All right reserved
Picture reference: 16036 - Date: 2023
Turbine 16037
Author: Gabriel Govaert - License: All right reserved
Picture reference: 16037 - Date: 2023
Turbine 16038
Author: Gabriel Govaert - License: All right reserved
Picture reference: 16038 - Date: 2023
Turbine 16039
Author: Gabriel Govaert - License: All right reserved
Picture reference: 16039 - Date: 2023
Turbine 16040
Author: Gabriel Govaert - License: All right reserved
Picture reference: 16040 - Date: 2023


Update for this sheet: 2 July 2024
